Fox ESS Evo 10.0 kW + 10.24 kWh Integrated Storage & Inverter System
#2: FE-EVO10-8H
Fox ESS Evo 8.0kW + 10.24kWh Battery Storage System UK
The Fox ESS EVO10-8H combines a powerful 8.0 kW hybrid inverter with a 10.24 kWh LiFePO₄ battery in one sleek, IP66-rated enclosure. Designed for UK installations, this solution supports backup power (EPS), parallel scalability, and export limitation, making it ideal for energy-conscious homeowners and installers.
This all‑in‑one hybrid inverter + battery system has been designed for an indoor or outdoor installation. This integration solution of a powerful inverter, high‑capacity battery, integrated Emergency Power Supply (EPS), and advanced smart monitoring comes in compact and aesthetically pleasing design.
This product is ideal for homeowners looking to:
-
Maximise solar self‑consumption
-
Have built‑in backup power in a grid outage
-
Deploy a minimalist, weatherproof design
-
Scale storage later when needed up to 30.72 kWh
-
This series is also suitable for light commercial applications where modular expansion is important.
With full UK compatibility (export limiting, CT/meter interaction, DRM/ESTOP), this model is built for the UK solar & storage market.
Key Benefits - Inverter
Maximum Power & Oversizing
-
8.0 kW inverter output
-
225 % PV oversize ratio (you can oversize your PV array up to ~2.25×)
MPPT & Input Flexibility
-
3 independent MPPT channels
-
80 V low start‑up voltage (enhanced early morning / low irradiation performance)
Display & Interface
-
Built-in LCD display with magnetic cover (for clean aesthetics)
-
Integrated Wi‑Fi (no external dongle required)
-
Support for export limitation via CT, meter, DRM0, ESTOP
EPS & Overload Capability
-
EPS (Emergency Power Supply) mode with up to 200 % overload capability
-
Parallel mode: up to 3 EVO units in parallel for increased capacity or power
-
Protection rating: IP66, suitable for outdoor installations
Key Benefits - Battery
Type & Chemistry
-
Integrated 10.24 kWh LiFePO₄ (LFP) battery
-
Scalable: up to 30.72 kWh when paralleling multiple units
Performance & Efficiency
-
Depth of Discharge (DoD): 95 %
-
High charge/discharge rates: up to 10 kW per unit
-
High round‑trip efficiency for reduced energy losses
Safety & Environmental Protection
-
IP66 rated enclosure (dust tight and heavy rain protection)
-
Integrated battery warm-up (to maintain performance in cold climates)
-
Built-in fire suppressant system
Technical Specifications: Inverter
| Inverter Rating | 8.0 kW |
| PV Oversize Capability | 225% |
| MPPT Inputs | 3 |
On/Off Grid Mode Supported
| Start Up Voltage | 80 V |
| Maximum DC Current | 20 A / 25 A Imp / Isc |
| Emergency Power Supply (EPS) | 200% capability |
| Export Limitation | CT / Meter / DRM0 / E‑Stop compatible |
| Communication | Integrated Wi-Fi (no external dongle required) |
| Parallel Mode | Up to 3 modules in parallel |
| Protection / Ingress Rating | IP66 |
| Weight | 115 kg |
| Display / Interface | LCD screen with magnetic protective cover |
Technical Specifications: Battery
| Battery Type | LiFePO₄ (LFP) integrated |
| Usable Capacity | 10.24 kWh |
| Maximum Scalable Capacity | 30.72 kWh (via parallel modules) |
| Maximum Charge / Discharge Rate | Up to 10 kW per unit |
| Depth of Discharge (DoD) | 95 % |
| Warm-up / Heating | Integrated battery warm-up system |
| Fire Safety | Built‑in fire suppressant |
| Protection Rating | IP66 (sealed for outdoor use) |
| Round-trip Efficiency | 95% |
Why Choose the Fox ESS Evo 8.0 kW System?
Perfect for UK Homeowners Who Want:
-
Lower energy bills
-
Grid independence & backup
-
Smart control of solar and storage
-
A modern, minimalist solution that’s built to last
-
Smart Monitoring & Control
- Easy Installation for Installers
-
All-in-One Simplicity — no separate inverter + battery boxes. Everything built into one unit.
-
Efficiency & Performance — supports 200% PV oversizing, ensuring you can maximise solar input.
-
Scalability & Flexibility — add more units later to scale capacity and flexibility.
-
Robust Safety Features — built-in fire suppression, integrated battery heating, and durable IP66 enclosure.
Please note: The standard warranty on the product is 5 years but it could be extended to 10 years in total after successful registration on the Fox website below.
https://www.fox-ess.com/warranty-registration-2/
