SolarEdge Single Phase Inverter – 10kW (HD-Wave)

Product Overview

The SolarEdge 10kW single phase inverter with HD-Wave technology is a cutting-edge solution designed to maximise energy harvest and system reliability. Compatible with SolarEdge power optimizers, it uses a simplified DC-to-AC conversion topology for higher efficiency, reduced size, and lighter weight. The inverter is ideal for residential solar PV systems seeking top-tier performance and ease of installation.

Key Features

• HD-Wave Technology – Latest generation inverter design, delivering record-breaking 99% efficiency.

• SetApp Commissioning – Inverter can be configured quickly via smartphone without a display.

• Optimiser-Based MPPT – Simplifies inverter design, improves reliability, and maintains peak efficiency regardless of string length or temperature.

• Award-Winning Design – Winner of the 2016 Intersolar Award and 2018 Edison Award.

• Extended Warranty Options – Standard 12-year warranty, extendable to 20 or 25 years.

Specifications

• Weight: 16.5 kg

• Rated Power: 10,000 W

• Max Input Voltage: 480 V

• Max DC Power: 20,000 W

• Max AC Power (5 Minutes): 10,000 W

• Surge AC Power (1 Second): 10,000 W

• Max DC Current: 25.5 A

• Number of MPPTs: 0 (handled in optimisers)

• DC Inputs: 3

• DC Fuses: None

• Connector Type: MC4 (6 included)

• Integrated DC Switch: Yes

• Euro Efficiency: 99%

• Transformer: None

• Phases: Single Phase

• Warranty: 12 years (extendable)

This inverter is perfect for homeowners looking for a high-efficiency, award-winning solar inverter that integrates seamlessly with SolarEdge optimisers and offers straightforward smartphone-based commissioning.
